The Oil Capacity of a 1996 Toyota Corolla 1.6

The 1996 Toyota Corolla 4-cylinder, 1.6-liter engine delivers 100 hp at 5,600 rpm. Proper care of the engine will ensure that it continues to produce the horsepower. Routine maintenance, such as changing the engine oil and filter, will keep the engine operating properly for many years.

Engine Oil Specifications

  • The 1996 Corolla 1.6-liter engine holds 3.2 quarts of oil. The oil and filter should be changed every 3,000 miles. Refill with 5W-30 to the proper level.

Electrical Specifications

  • The battery voltage should be 12 volts or greater. While the engine is running and the alternator is charging, the battery voltage will be approximately 13.2 volts. The battery terminals should be tight and clean of corrosion, oil and dirt. The spark plug wires should be free of abrasion and corrosion. The spark plug gap should be set to 0.032 inches. Proper firing order is 1-3-4-2.

    Proper maintenace will prolong the life of your car.
    Proper maintenace will prolong the life of your car.

Other Considerations

  • Maintain proper coolant level by refilling the system with a 50/50 mixture of ethylene glycol and water. The drive belts should be clean and free from oil, major cracks and abrasions. Replace the engine fuel air filters as required in the maintenance schedule found in your owner's manual.
