The air mass sensor, also known as the mass airflow sensor, or MAF, is located in the air intake tract on a Dodge Stratus and measures the molecular weight of air entering the engine. This information is relayed to the engine computer and helps to determine fuel injector pulse width by turning the injectors on and off. Replacing the air mass sensor on a Dodge Stratus can be accomplished with a few simple tools.
Loosen the bolt that secures the negative battery cable to the battery, using a wrench. Then pull the cable off the battery.
Locate the air mass sensor. It will be located on the air intake tract.
Separate the wiring harness from the air mass sensor. Pry the retaining clip away from the sensor, using a flat blade screwdriver. Then pull the wiring connector off the sensor.
Loosen the hose clamp that secures the intake tract to the intake housing, using a socket. Then pull the tract away from the housing.
Unhook the latches that secure the air filter housing lid to the base with your hand. Then pull the lid and air filter off the base and remove it from the vehicle.
Unscrew the three bolts on the bottom of the air filter base, using a socket. Then pull the base from the engine bay.
Unscrew the bolts that secure the sensor to the intake tract. Then pull the sensor from the intake tract.
Lay a new gasket between the intake tract and the air mass sensor. Then screw in the bolts that connect the sensor to the tract, using a socket.
Drop the air filter housing base into position and screw in the bolts that secure it to the vehicle’s chassis, using a socket.
Drop the air filter and cover into position. Close the latches that secure the air filter cover to the base, using your hand.
Slide the air intake tract onto the air filter housing cover. Tighten the hose clamp, using a socket.
Press the wiring harness onto the air mass sensor.
Slide the negative battery cable onto the negative battery post. Tighten the retaining bolt, using a wrench.
