The Toyota FJ Cruiser's factory radio requires you to remove the dash for any repairs or replacement installation. The FJ Cruiser's dash is easily removed with a Phillips screwdriver, a 10 mm socket wrench and a panel removal tool. When installing a aftermarket stereo system you will need a dash assembly kit to fit the new system inside the factory dash.
Disconnect the car battery's negative terminal with a 1/2-inch wrench. This will prevent any short circuits.
Remove the two Phillips screws with a No. 0 Phillips screwdriver, located at the bottom of the side trim panel.
Pry gently with the panel removal tool or nylon pry bar to remove the side trim panel. Start by prying the bottom corners then gently pry the top corners of the side trim panel. Only use a panel removal tool or nylon pry bar, since these tools give enough flexibility to pry without cracking or damaging the panel.
Remove the two Phillips screws with a No. 0 Phillips screwdriver from the side metal brackets of radio trim panel to gain access to the radio. The radio trim panel is a section of the dash that contains the hazard light and climate control knobs.
Pry gently with the panel removal tool or nylon pry bar to remove the radio trim panel. When prying, work your way gently around the panel to loosen before you remove.
Remove the four 10 mm bolts with a 10 mm socket wrench. These bolts are securing the radio to the housing bracket.
Unplug the radio connectors and remove.
