The Hankook Dynapro RF10 is a tire built for aggressive driving on all terrain. Primary applications for this tire are SUVs (Sport Utility Vehicles), light trucks, minivans, and small to medium sized vans. Hankook is known for producing high-quality tire products, although many of its tires, including the Dynapro RF10, can be quite expensive.
Several different sizes are available for the Dynapro ATM RF10. Sizes range from between 15 inches in diameter to 22 inches. The largest and widest tire is sized at "LT325/50R22E2 122S B" and the smallest and thinnest tire is sized at "LT235/75R15C1 104R W." For a full list of tire sizes, click on the first link in the Resources.
The Hankook Dynapro ATM RF10 is built for rugged, off road use. A 6-ply sidewall constructed from 2 plies of steel, 2 plies of nylon, and 2 plies of polyester protects the tire from sharp objects puncturing the side of the wheel. The sidewall type is OWL (Outline White Lettering).
Maximum loads vary greatly depending on the tire size you purchase; a large "LT285/70R17" RF10 sustains a maximum load of 3,750 pounds at 80 PSI (Pounds per Square Inch), whereas a smaller "LT285/70R17" has a maximum load capacity of 1,985 PSI at 80 PSI. Tread depth for the large "LT285/70R17" is 16.5/32 inches, which is nearly one half of an inch. Tread depth for the smaller "LT285/70R17" is exactly the same, measuring at 16.5 inches.
