Checking the automatic transmission fluid (ATF) level in the Chrysler 300C is challenging for the owner performing basic maintenance as there is no dipstick provided. Checking the fluid is typically done by the dealer using a special dipstick tool and a chart. Purchasing this special tool online and following simple instructions will permit the consumer to confirm the appropriate automatic transmission fluid level.
Log onto MillerSpecialTools.com and purchase Tool Model Number 9336A. This tool retails for $51.72 as of October 2010.
Measure the fluid level by inserting the Miller dipstick into the ATF pipe located in the engine compartment. Read the fluid level indicated on the dipstick, noting the temperature variances when the transmission is cold (30 mm), warm (50 mm) or hot (80 mm).
Add 7 quarts of ATF if the transmission has been removed, then warm up the car and check the level with the 9336 dipstick and top off with fluid as needed. If the transmission was completely overhauled or the torque converter was drained or replaced, add 8.5 quarts.
