How to Fix a Toyota Camry Brake Light

Eventually all light bulbs burn out. Over time the same is true for your Toyota Camry brake lights. Fixing the brake light is only a matter of replacing the burned out bulb with a new bulb and is a relatively easy task you can perform yourself without the need for a skilled mechanic or special tools.

Things You'll Need

  • 5W type C brake bulb
  • Open the driver's side door and pull the trunk release switch. Open the trunk.

  • Find the rear light assembly cover in the trunk. Note that it is a hard plastic rectangular cover directly behind each rear light assembly.

  • Locate which light needs replacement and make a mental note. Have a partner look at the brake lights while you depress the brake petal, if you are unsure.

  • Grasp the sides of the cover firmly and pull it open. There is a hinge on the outer side of the cover.

  • Locate the center bulb. This is the brake light bulb.

  • Twist the bulb and connecting electrical boot counterclockwise and pull it directly out of the light assembly.

  • Remove the bulb from the electrical boot by pulling it directly out.

  • Insert a new 5W type C brake light bulb into the electrical boot. Push the bulb directly into the boot until it is snugly connected.

  • Insert the electrical boot back into the light assembly, lining up the pins on the boot with the cut-out sections in the assembly. Twist the boot clockwise to secure it.

  • Test the brakes and have a partner check to make sure the new bulb is working properly.

  • Swing the cover closed and press it until you hear an audible "click." Close the trunk.
