Fog lights might add a certain stylistic touch to your vehicle, but they also serve an important job. They keep you safe during adverse driving conditions (like fog and rain) by providing extra illumination on the roadway. Over time the bulbs will burn out; replace them as soon as possible. Unfortunately, on most Sante Fe models, access to the fog lights doesn't come easily: You must detach the front bumper, according to Hyundai. The project vehicle discussed here is a 2003 Hyundai Sante Fe, but the process is similar for other models as well.
Open and prop up the hood of the Hyundai Santa Fe.
Locate the headlight assembly on the side of the car in need of the replace the fog light.
Pull out the three headlight mounting bolts, using a ratchet and socket.
Use a screwdriver to twist out the six screws atop the front bumper cover. Pull the front bumper cover away from the vehicle.
Remove the five screws that secure the front bumper to the vehicle, using the screwdriver. Also remove the two screws on the outside edge of the front wheel guard. Set aside both the front bumper and the front wheel guard. Now you have direct access to the fog light assembly.
Pull out the fog light assembly by hand.
Turn the assembly over, and twist the bulb half a turn counterclockwise with your hand to pull it out of the assembly. Detach the bulb from the wiring connector.
Attach the replacement fog bulb to the connector, then slide it into the assembly. Turn it clockwise to lock it into place.
Return the parts to the Santa Fe in reverse order of removal.
Close the hood, and try out the Santa Fe fog lights by turning them on from inside the vehicle.
